Comunicación vía sockets: ejecución

Clase 36 de 37 • Curso de Introducción a C 2019

Sebastian Andree Lopera Quevedo

student•

luche un poco para ver algunos errores, no me compilaba. Al final vi lo que mis compañeros dejaron y vi la logica de mi código porque el error no era de sintaxis. Gracias a mis compañeros de curso logre ver que me faltaron paréntesis por algun lado jaja tengan cuidado. Les dejo mi código por si quieren comparar si tienen problemas:

SERVIDOR

//libraries with the needed definitions:
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
/*
struct sockaddr_in
{
  short int sin_family;
  unsigned short int sin_port;
  struct in_addr sin_addr;
  unsigned char sin_zero[8];
};

struct sockaddr
{
  unsigned short sa_family;
  char sa_data[14];
};

int socket(int domain, int type, int protocol);

int bind(int sockfd, const struct sockaddr *myaddr, int addrlen);

int listen(int s, int backlog);

int accept(int sockfd, const struct sockaddr *addr, socklen_t addrlen);

ssize_t send(int sockfd, const void *buf, size_t len, int flags);

ssize_t recv(int sockfd,       void *buf, size_t len, int flags);

int shotdown();
*/

#include <string.h>
#include <stdlib.h>
#include <stdio.h>

int main(int argc, char const *argv[])
{
  //the first argument will be the port of communication
  if (argc > 1)
  {
    //the needed variables
    int server_socket, client_socket, longitud_cliente, port;

    //casting the argument to an integer
    port = atoi(argv[1]);

    //defining the n-points
    struct sockaddr_in server;
    struct sockaddr_in client;

    // server variables
    server.sin_family = AF_INET;//protocol type (TCP-IP)
    server.sin_port = htons(port);//the integer with the port number gets transformed to the needed structure
    server.sin_addr.s_addr = INADDR_ANY;//any client could get connected
    bzero(&(server.sin_zero), 8);//this function fulls a string with 0's

    if ((server_socket = socket(AF_INET, SOCK_STREAM, 0)) == -1)
    //a socket is created for the server (protocol family, specific protocol (TCP/IP), configuration (0 for automatic configuration))
    //if the function goes right returns a value different of -1
    {
      printf("no pude abrir el socket\n");//printed in case of opening error

      return 1;
    }
    if (bind(server_socket, (struct sockaddr *) &server, sizeof(struct sockaddr)) == -1)
    //the server socket is associated to a port (the scoket, a pointer to a socket address structure for the configuration, size of the structure)
    //if the function goes right returns a value different of -1
    {
      printf("no pude abrir el puerto %s y asociarlo con el socket\n", argv[1]);//this could happen if the port is already opened by other application

      return 2;
    }

    if (listen(server_socket, 5) == -1)
    //the port now is listening for only 5 clients
    //if the function goes right returns a value different of -1
    {
      printf("no pude ponerme en modo escucha\n");

      return 3;
    }

    //accepting clients
    printf("Todo listo! Aceptando clientes...\n");
    longitud_cliente = sizeof(struct sockaddr_in);
    if ((client_socket = accept(server_socket, (struct sockaddr *) &client, &longitud_cliente)) == -1)
    //accepts the first client waiting for service (the server_socket accepts the conection, a pointer to a socket address structure for the configuration, size of the structure)
    //if the function goes right returns a value different of -1
    {
      printf("No se pudo establecer conección con \n");

      return 4;
    }

    //at this point the conection has been established

    //in order to see the client's direction...
    char str[INET_ADDRSTRLEN];
    //...transforms a direction to a string (protocol, direction to trasform, pointer to a buffer where the address is going to be saved, max size of the buffer)
    inet_ntop(AF_INET, &(client.sin_addr), str, INET_ADDRSTRLEN);

    //it advice the client connected, his IP and port
    printf("Se conectó un cliente desde la IP: %s, desde el puerto: %d\tlo saludo\n", str, port);

    //send a message to the client (to who, message, size of the message, modificators bit to bit (0 for no one))
    send(client_socket, "Bienvenido a mi pedilecto, sublime y elegante servidor.", 55, 0);

    //advice that the graet has been sent
    printf("Saludo enviado!\n");

    //closing the communication(closing socket, how it gonna be closed (2 for be closed completly))
    shutdown(client_socket, 2);
    shutdown(server_socket, 2);
  }
  else
  //if the port has not been passed by the command parameter
  {
    printf("No se indicó el puerto\n");

    return 5;
  }

  return 0;
}

CLIENTE

//libraries with the needed definitions:
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
/*
struct sockaddr_in
{
  short int sin_family;
  unsigned short int sin_port;
  struct in_addr sin_addr;
  unsigned char sin_zero[8];
};

struct sockaddr
{
  unsigned short sa_family;
  char sa_data[14];
};

int socket(int domain, int type, int protocol);

int bind(int sockfd, const struct sockaddr *myaddr, int addrlen);

int listen(int s, int backlog);

int accept(int sockfd, const struct sockaddr *addr, socklen_t addrlen);

ssize_t send(int sockfd, const void *buf, size_t len, int flags);

ssize_t recv(int sockfd,       void *buf, size_t len, int flags);

int shotdown();
*/

#include <string.h>
#include <stdlib.h>
#include <stdio.h>

int main(int argc, char const *argv[])
{
  //the first argument will be the server IP
  //the second argument will be the communication port
  if (argc > 2)
  {
    //a string that holds the server IP
    const char *ip;
    //a socket for the client, the amount of bytes that will be recieved or sent, the port
    int client_socket, numbytes, port;

    char buff[100];//pff it's a buffer

    //giving the respective values to the IP and port
    ip = argv[1];
    port = atoi(argv[2]);
    //server information
    struct sockaddr_in server;

    if (inet_pton(AF_INET, ip, &server.sin_addr) <= 0)
    //convert the argument to an IP address (protocol family, specific protocol (TCP/IP), configuration (0 for automatic configuration))
    ////if the function goes right returns a value different of -1
    {
      printf("la IP %s no es valida\n", ip);

      return 1;
    }

    //creating the client socket
    printf("Abriendo el socket del cliente...\n");
    if ((client_socket = socket(AF_INET, SOCK_STREAM, 0)) == -1)
    //a socket is created for the client (protocol family, specific protocol (TCP/IP), configuration (0 for automatic configuration))
    //if the function goes right returns a value different of -1
    {
      printf("no pude abrir el socket\n");

      return 2;
    }

    //server variables to especify which server to connect to
    server.sin_family = AF_INET;//protocol type (TCP-IP)
    server.sin_port = htons(port);//the integer with the port number gets transformed to the needed structure
    bzero(&(server.sin_zero), 8);//this function fulls a string with 0's

    //trying to get connected
    printf("Conectando a IP: %s, desde el puerto: %d\n", ip, port);
    if (connect(client_socket, (struct sockaddr *) &server, sizeof(struct sockaddr)) == -1)
    //the client socket is connecting to a server (the scoket, a pointer to a socket address structure for the configuration, size of the structure)
    //if the function goes right returns a value different of -1
    {
      printf("no pude conectarme al servidor\n");

      return 3;
    }

    //recieving message and printing it
    printf("Recibiendo...\n");////////////////
    if ((numbytes = recv(client_socket, buff, 100, 0)) == -1)
    //recieve a message from the server (///////////to who, a pointer to the buffer where the message is gonna be saved, size of the buffer, modificators bit to bit (0 for no one))
    //if the function goes right returns a value different of -1
    {
      printf("no se recibio el mensaje\n");

      return 4;
    }
    buff[numbytes] = '\0';
    printf("El servidor envia:\t'%s'\n", buff);

    //closing the communication(closing socket, how it gonna be closed (2 for be closed completly))
    shutdown(client_socket, 2);
  }
  else
  //if the port has not been passed by the command parameter
  {
    printf("No se indico la IP o el puerto\n");

    return 5;
  }

  return 0;
}```


Todo está bastante bien comentado en inglés asi que espero les sirva.
